Caldwell  |  SKU: Caldwell-TLC-00.50-A

Caldwell Locking Curved Plate and Pipe Clamp

$1,416.00
Request a Quote

The Model TLC is a vertical lifting clamp incorporating a “Lock Open” and a “Lock Closed” feature. The clamp is recommended for lifting and turning of a single curved plate/pipe from horizontal to vertical to horizontal. The “Lock Open”, “Lock Closed” feature facilitates attaching and removing the clamp from the curved plate/pipe.

Specifications

Capacity 0.5

Available Models

Part No. Rated Capacity Clamp Body Length Clamp Body Width Jaw Height Jaw Length Overall Clamp Height Overall Length Plate Thickness Max Shackle Opening Shackle Thickness Inside Wall R min Temp Weight
TLC-00.50-A 1000 6.25 2.75 1.81 2.38 4.75 11.13 0.63 2.38 0.5 3.38 9
TLC-01.00-A 2000 7.5 2.81 2 3 6 13.13 0.75 2.44 0.63 3.75 14
Caldwell Locking Curved Plate and Pipe Clamp
Caldwell

Caldwell Locking Curved Plate and Pipe Clamp

From $1,416.00

The Model TLC is a vertical lifting clamp incorporating a “Lock Open” and a “Lock Closed” feature. The clamp is recommended for lifting and turning of a single curved plate/pipe from horizontal to vertical to horizontal. The “Lock Open”, “Lock Closed” feature facilitates attaching and removing the clamp from the curved plate/pipe.

Specifications

Capacity 0.5

Available Models

Part No. Rated Capacity Clamp Body Length Clamp Body Width Jaw Height Jaw Length Overall Clamp Height Overall Length Plate Thickness Max Shackle Opening Shackle Thickness Inside Wall R min Temp Weight
TLC-00.50-A 1000 6.25 2.75 1.81 2.38 4.75 11.13 0.63 2.38 0.5 3.38 9
TLC-01.00-A 2000 7.5 2.81 2 3 6 13.13 0.75 2.44 0.63 3.75 14

Rated Capacity

  • 1000
  • 2000
View product
