Caldwell | SKU:
Caldwell-MM-1/4-10
Caldwell Manual Trolley, Manual Hoist
$979.00
Unit price
/
Unavailable
Caldwell Manual Trolley, Manual Hoist - 0.25 / 10 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
This product is available but requires more information!
Call (405) 672-0531 or fill out the form for custom pricing:
Caldwell Manual Trolley, Manual Hoist
From
$705.00
Unit price
/
Unavailable
Features
- Heavy duty design
- Upper and lower limit switch
- Thermal protected fan cooled motor
- Bottom swivel hook with safety latch
- Chain container
- Ergonomically designed push button station
Available Models
| Part No. | Capacity (ton) | Lift | Capacity | Rated Capacity | Max Flange Range B | Min Flange Range A | Max Flange Range A | Min Flange Range B | G | C | D | Headroom |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MM-1/4-10 | 0.25 | 10 | 0.25 | 500 | 8 | 2.28 | 4 | 4.01 | 1.1 | 0.7 | 7.2 | 16.1 |
| MM-1/4-15 | 0.25 | 15 | 0.25 | 500 | 8 | 2.28 | 4 | 4.01 | 1.1 | 0.7 | 7.2 | 16.1 |
| MM-1/4-20 | 0.25 | 20 | 0.25 | 500 | 8 | 2.28 | 4 | 4.01 | 1.1 | 0.7 | 7.2 | 16.1 |
| MM-1/2-10 | 0.5 | 10 | 0.5 | 1000 | 8 | 2.28 | 4 | 4.01 | 1.1 | 0.7 | 7.2 | 16.1 |
| MM-1/2-15 | 0.5 | 15 | 0.5 | 1000 | 8 | 2.28 | 4 | 4.01 | 1.1 | 0.7 | 7.2 | 16.1 |
| MM-1/2-20 | 0.5 | 20 | 0.5 | 1000 | 8 | 2.28 | 4 | 4.01 | 1.1 | 0.7 | 7.2 | 16.1 |
| MM-1-10 | 1 | 10 | 1 | 2000 | 8 | 2.28 | 5 | 5.01 | 1.1 | 0.9 | 9.3 | 18.3 |
| MM-1-15 | 1 | 15 | 1 | 2000 | 8 | 2.28 | 5 | 5.01 | 1.1 | 0.9 | 9.3 | 18.3 |
| MM-1-20 | 1 | 20 | 1 | 2000 | 8 | 2.28 | 5 | 5.01 | 1.1 | 0.9 | 9.3 | 18.3 |
| MM-2-10 | 2 | 10 | 2 | 4000 | 12 | 3.23 | 6.02 | 6.03 | 1.4 | 1.2 | 11 | 24.8 |
| MM-2-15 | 2 | 15 | 2 | 4000 | 12 | 3.23 | 6.02 | 6.03 | 1.4 | 1.2 | 11 | 24.8 |
| MM-2-20 | 2 | 20 | 2 | 4000 | 12 | 3.23 | 6.02 | 6.03 | 1.4 | 1.2 | 11 | 24.8 |
| MM-3-10 | 3 | 10 | 3 | 6000 | 12 | 3.23 | 6.02 | 6.03 | 1.7 | 1.5 | 12.8 | 29.5 |
| MM-3-15 | 3 | 15 | 3 | 6000 | 12 | 3.23 | 6.02 | 6.03 | 1.7 | 1.5 | 12.8 | 29.5 |
| MM-3-20 | 3 | 20 | 3 | 6000 | 12 | 3.23 | 6.02 | 6.03 | 1.7 | 1.5 | 12.8 | 29.5 |
| MM-5-10 | 5 | 10 | 5 | 10000 | 12 | 4.92 | 7.02 | 7.03 | 1.8 | 1.9 | 13.7 | 27.7 |
| MM-5-15 | 5 | 15 | 5 | 10000 | 12 | 4.92 | 7.02 | 7.03 | 1.8 | 1.9 | 13.7 | 27.7 |
| MM-5-20 | 5 | 20 | 5 | 10000 | 12 | 4.92 | 7.02 | 7.03 | 1.8 | 1.9 | 13.7 | 27.7 |
