Caldwell | SKU:
Caldwell-BD-00.50-A
Caldwell Model BD Non-Locking Type
$597.00
Unit price
/
Unavailable
Caldwell Model BD Non-Locking Type - 0.5 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
This product is available but requires more information!
Call (405) 672-0531 or fill out the form for custom pricing:
Caldwell Model BD Non-Locking Type
From
$597.00
Unit price
/
Unavailable
The Model BD is a vertical lifting, non-locking clamp used primarily for steel warehousing and bench work where a locking type clamp is not essential. The clamp is a low-cost, low-maintenance tool that features lightweight and compact size. It is recommended for use and application where constant tension is applied to the lifting shackle throughout the entire operation.
Features
- Ergonomic lightweight design & compact size
- Vertical non-locking clamp for steel warehousing & bench work
- Recommended for use where constant tension is applied to the lifting shackle
- Lower cost & low maintenance design
Available Models
| Part No. | Capacity (ton) | Capacity | Rated Capacity | Shackle Hole Diameter | Jaw Height | Shackle Thickness | Clamp Height | Clamp Length | Clamp Width | Jaw Length | Overall Length | Plate Thickness Max |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BD-00.50-A | 0.5 | 0.5 | 1000 | 1.75 | 1.38 | 0.5 | 4.5 | 6.31 | 2.25 | 2.56 | 10.38 | 1 |
| BD-01.00-A | 1 | 1 | 2000 | 2.5 | 1.62 | 0.62 | 5.56 | 7.31 | 2.88 | 3.06 | 12.75 | 1.12 |
| BD-02.00-A | 2 | 2 | 4000 | 3.12 | 2.25 | 0.62 | 6.56 | 8.06 | 3 | 3.56 | 14.5 | 1.38 |
| BD-04.00-A | 4 | 4 | 8000 | 3.12 | 2.25 | 0.75 | 7.44 | 10.75 | 3.88 | 3.88 | 17.75 | 1.75 |
| BD-07.00-A | 7 | 7 | 14000 | 3.88 | 3 | 1 | 9.62 | 12.75 | 5 | 5 | 22.5 | 2.5 |
