Caldwell | SKU:
Caldwell-HRS-00.25-A
Caldwell Model HRS Type
$1,147.00
Unit price
/
Unavailable
Caldwell Model HRS Type - 0.25 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
This product is available but requires more information!
Call (405) 672-0531 or fill out the form for custom pricing:
Caldwell Model HRS Type
From
$1,147.00
Unit price
/
Unavailable
The Model HRS is a horizontal lifting clamp that has a spring loaded open and closed position. The spring closed position allows one-man operation of multiple clamps. The clamps stay in position where they are attached until spring open is actuated. These clamps must be used in pairs, sets of pairs, or in a tripod arrangement for transporting plates horizontally.
Features
- Spring loaded open & closed position
- Spring closed position allows single person operation of multiple clamps
- Must be used in pairs, sets of pairs or tripod arrangement
Specifications
| Min Jaw Opening | 0.06 |
Available Models
| Part No. | Capacity (ton) | Capacity | Rated Capacity | Shackle Hole Diameter | Cam Thickness | Clamp Length | Clamp Width | Jaw Length | Jaw Thickness | Jaw to Clamp Height | Max Jaw Opening | Temp Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| HRS-00.25-A | 0.25 | 0.25 | 500 | 0.5 | 0.5 | 4.75 | 3 | 3 | 0.38 | 2.56 | 0.75 | 4 |
| HRS-00.50-A | 0.5 | 0.5 | 1000 | 0.5 | 0.5 | 5.94 | 3.25 | 3.75 | 0.5 | 3.31 | 1 | 5 |
| HRS-01.00-A | 1 | 1 | 2000 | 0.62 | 0.62 | 6.19 | 3.5 | 4 | 0.62 | 3.69 | 1.25 | 7 |
| HRS-02.00-A | 2 | 2 | 4000 | 1.06 | 0.75 | 8.62 | 5 | 5.38 | 0.75 | 4.5 | 1.5 | 20 |
| HRS-03.00-A | 3 | 3 | 6000 | 1.25 | 1 | 10.75 | 7 | 6.75 | 1 | 5.75 | 1.75 | 34 |
| HRS-04.00-A | 4 | 4 | 8000 | 1.25 | 1 | 10.75 | 7 | 6.75 | 0.75 | 5.75 | 2 | 44 |
