Caldwell  |  SKU: Caldwell-SCP-00.50-A

Caldwell Model SCP Locking, Screw Type

$1,163.00
Request a Quote

The Model SCP clamp is capable of handling steel plate from horizontal to vertical to horizontal through a 180° arc and may be used for handling plate a trolling and forming machines. These clamps feature a spring loaded pivoting cam jaw that "cams in" when a load is applied to the lifting shackle. Clamp is capable of handling plate horizontally when used in pairs or sets of pairs, or in a tripod arrangement.

Features

  • Developed to handle plate at rolling & forming machines
  • Single plate handling from horizontal to vertical to horizontal through a 180° arc
  • Features a spring loaded pivoting jaw to engage when a load is applied
  • Can be used in pairs, sets of pairs or tripod arrangement when lifting horizontally
  • Heavy-duty screw-clamp version of the Model RSC

Available Models

Part No. Capacity (ton) Capacity Rated Capacity Shackle Opening Shackle Thickness Clamp Height Clamp Width Jaw Height Jaw Length Overall Height Overall Length Plate Thickness Max
SCP-00.50-A 0.5 0.5 1000 2.38 0.5 4.5 2.38 2.38 1.88 9 6.62 0.75
SCP-01.50-A 1.5 1.5 3000 2.62 0.62 5.5 3.38 2.88 2.38 10.56 8.44 1.25
SCP-03.00-A 3 3 6000 2.38 0.75 5.75 4.06 3.12 2.81 12 10.81 2
SCP-06.00-A 6 6 12000 3 1 7.56 5.38 4.31 3.44 14.38 14.38 2.5
SCP-10.00-A 10 10 20000 3.25 1 9.75 6.75 5.5 4.38 19.25 16.38 3
SCP-15.00-A 15 15 40000 3.75 1.25 12.12 8.25 7.25 5.56 22.88 21.5 4
