Esmet Electroline | SKU:
ELU-IKA-218
Eye Socket Fitting for Braided Jacket Kevlar Rope
$61.90
Unit price
/
Unavailable
Eye Socket Fitting for Braided Jacket Kevlar Rope - 3/16 is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
This product is available but requires more information!
Call (405) 672-0531 or fill out the form for custom pricing:
Eye Socket Fitting for Braided Jacket Kevlar Rope
From
$61.90
Unit price
/
Unavailable
Designed for Kevlar ropes with a braided jacket, this fitting features an eye connector and a swageless termination that allows the fitting to be quickly installed in the field without special tools or processes.
Available for ropes 3/16 to 3/4" in size.
Machined from aluminum to provide lightweight strength.
Available Products
| Rope Size (In.) | Part No. | Breaking Strength (lbs.) | Dimensions (In.) | |||||
|---|---|---|---|---|---|---|---|---|
| A | B | C | D | E | F | |||
| 3/16 | IKA-218 | 2400 to 4400 | 1/2" | 13/16" | 5-9/16" | 1" | 23/64" | 25/64" |
| 1/4 | IKA-225 | 4400 to 6000 | 19/32" | 27/32" | 6-7/8" | 1-1/8" | 23/64" | 29/64" |
| 5/16 | IKA-231 | 6000 to 9000 | 21/32" | 31/32" | 7-15/16" | 1-1/2" | 27/64" | 33/64" |
| 3/8 | IKA-237 | 9000 to 13000 | 21/32" | 1-1/16" | 8-15/16" | 1-1/2" | 31/64" | 41/64" |
| 1/2 | IKA-250 | 16000 to 22000 | 27/32" | 1-3/8" | 11-1/4" | 1-3/4" | 3/4" | 61/64" |
| 5/8 | IKA-262 | 28000 to 37000 | 1-1/2" | 2" | 14-3/4" | 2-1/2" | 1-1/4" | 1-5/32" |
| 3/4 | IKA-275 | 35000 to 63000 | 2" | 2-1/2" | 17-1/4" | 3" | 1-3/8" | 1-13/32" |
